IGR 17 Series is a high-performance industrial gateway engineered specifically for remote firmware updates on machinery vehicles operating in harsh environments. When integrated with a remote access server and cloud platform, it forms a robust remote operation and maintenance center for equipment.
The solution enables online troubleshooting and real-time monitoring of devices equipped with CAN, Ethernet, and RS232 interfaces. By minimizing on-site visits, it significantly reduces operational costs and improves overall efficiency.
- Operating temperature: -20℃～+60℃.
- Relative humidity: 5% ~ 95%
- Material: Metal casing
- Installation method: Bolted
- 1-year warranty
- Power supply: 12-24V DC
- 1 x 10/100 Mbps Ethernet (supports LAN, static IP, and DHCP)
- 1 x RS232
- 1 x CAN bus
- Number of channels: 2 remote access channels
- For remote access of CAN interface devices programmed with CodeSys 2.3 for EPEC controllers
- Supports remote access of CAN devices with Ethernet/RS232 interfaces
- Number of channels: 1 CAN bus
- Supported protocols: CAN OPEN
- Supported cloud platforms: RMC. Customized private cloud support available
